Example: voice note transcription

This example builds a plugin that listens for WhatsApp voice notes, sends the decrypted audio to OpenAI's transcription API, and replies to the sender with the text.

What the plugin does

When someone sends a voice note to your WhatsApp session:

The plugin detects it is a voice note
Decrypts the audio data
Sends it to a speech-to-text API
Replies to the sender with the transcription as a quoted message

Detect voice notes

Voice notes arrive as messages with specific properties:

type VoiceNoteMessage = {
  type: 'audio';
  mimetype: string;
  from: string;
  id: string;
};

function getVoiceNote(message: unknown): VoiceNoteMessage | null {
  if (!message || typeof message !== 'object') return null;

  const candidate = message as {
    type?: unknown;
    mimetype?: unknown;
    from?: unknown;
    id?: unknown;
  };

  if (candidate.type !== 'audio') return null;
  if (typeof candidate.mimetype !== 'string' || !candidate.mimetype.includes('ogg')) return null;
  if (typeof candidate.from !== 'string' || typeof candidate.id !== 'string') return null;

  return {
    type: 'audio',
    mimetype: candidate.mimetype,
    from: candidate.from,
    id: candidate.id,
  };
}

'message.received': async ({ message, logger }) => {
  const voiceNote = getVoiceNote(message);

  if (!voiceNote) return;

  logger.info('Voice note received');
}

Decrypt media

Use client.decryptMedia to get the raw audio bytes:

function errorMessage(error: unknown) {
  return error instanceof Error ? error.message : String(error);
}

'message.received': async ({ message, client, logger }) => {
  const voiceNote = getVoiceNote(message);

  if (!voiceNote) return;

  try {
    const mediaData = await client.decryptMedia(message);
    // mediaData is a Buffer containing the OGG audio
    logger.info('Media decrypted', { size: mediaData.length });
  } catch (error) {
    logger.error('Failed to decrypt media', { error: errorMessage(error) });
  }
}

Call the transcription API

Send the audio to a speech-to-text service. This example uses OpenAI's audio transcription endpoint:

async function transcribe(audioBuffer: Buffer, apiKey: string): Promise<string> {
  const formData = new FormData();
  formData.append('file', new Blob([audioBuffer]), 'audio.ogg');
  formData.append('model', 'whisper-1');

  const response = await fetch('https://api.openai.com/v1/audio/transcriptions', {
    method: 'POST',
    headers: {
      'Authorization': `Bearer ${apiKey}`,
    },
    body: formData,
  });

  if (!response.ok) {
    throw new Error(`STT API error: ${response.status}`);
  }

  const result = await response.json() as { text?: unknown };

  if (typeof result.text !== 'string') {
    throw new Error('STT API response did not include text');
  }

  return result.text;
}

Reply with the transcript

Use client.reply to send the transcription as a quoted reply:

'message.received': async ({ message, client, logger }) => {
  // ... after transcription ...
  const voiceNote = getVoiceNote(message);

  if (!voiceNote) return;

  const transcription = await transcribe(mediaData, config.apiKey);

  await client.reply(voiceNote.from, transcription, voiceNote.id);
  logger.info('Transcription sent');
}

Configuration

Use Zod for configuration validation so the plugin fails at startup when the API key is missing:

import { createPlugin } from '@open-wa/plugin-sdk';
import { z } from 'zod';

const configSchema = z.object({
  apiKey: z.string().min(1, 'STT API key is required'),
  language: z.string().default('en'),
  enabled: z.boolean().default(true),
});

export default createPlugin({
  meta: { name: 'voice-transcriber' },
  configSchema,
  init: async ({ events, logger, config, client }) => {
    if (!config.enabled) {
      logger.info('Plugin disabled');
      return;
    }

    logger.info('Voice transcriber loaded');

    events.on('message.received', async ({ message }) => {
      const voiceNote = getVoiceNote(message);

      if (!voiceNote) return;

      try {
        const mediaData = await client.decryptMedia(message);
        const transcription = await transcribe(mediaData, config.apiKey);
        await client.reply(voiceNote.from, transcription, voiceNote.id);
        logger.info('Transcription sent');
      } catch (error) {
        logger.error('Transcription failed', { error: errorMessage(error) });
      }
    });
  },
});

Full code example

// voice-transcriber.ts
import { createPlugin } from '@open-wa/plugin-sdk';
import { z } from 'zod';

type VoiceNoteMessage = {
  type: 'audio';
  mimetype: string;
  from: string;
  id: string;
};

function getVoiceNote(message: unknown): VoiceNoteMessage | null {
  if (!message || typeof message !== 'object') return null;

  const candidate = message as {
    type?: unknown;
    mimetype?: unknown;
    from?: unknown;
    id?: unknown;
  };

  if (candidate.type !== 'audio') return null;
  if (typeof candidate.mimetype !== 'string' || !candidate.mimetype.includes('ogg')) return null;
  if (typeof candidate.from !== 'string' || typeof candidate.id !== 'string') return null;

  return {
    type: 'audio',
    mimetype: candidate.mimetype,
    from: candidate.from,
    id: candidate.id,
  };
}

function errorMessage(error: unknown) {
  return error instanceof Error ? error.message : String(error);
}

const configSchema = z.object({
  apiKey: z.string().min(1, 'STT API key is required'),
  language: z.string().default('en'),
  enabled: z.boolean().default(true),
});

async function transcribe(audioBuffer: Buffer, apiKey: string, language: string): Promise<string> {
  const formData = new FormData();
  formData.append('file', new Blob([audioBuffer]), 'audio.ogg');
  formData.append('model', 'whisper-1');
  formData.append('language', language);

  const response = await fetch('https://api.openai.com/v1/audio/transcriptions', {
    method: 'POST',
    headers: {
      'Authorization': `Bearer ${apiKey}`,
    },
    body: formData,
  });

  if (!response.ok) {
    throw new Error(`STT API error: ${response.status} ${response.statusText}`);
  }

  const result = await response.json() as { text?: unknown };

  if (typeof result.text !== 'string') {
    throw new Error('STT API response did not include text');
  }

  return result.text;
}

export default createPlugin({
  meta: { name: 'voice-transcriber' },
  configSchema,
  init: async ({ events, logger, config, client }) => {
    if (!config.enabled) {
      logger.info('Voice transcriber disabled');
      return;
    }

    logger.info('Voice transcriber loaded');

    events.on('message.received', async ({ message }) => {
      const voiceNote = getVoiceNote(message);

      if (!voiceNote) return;

      try {
        const mediaData = await client.decryptMedia(message);
        logger.info('Media decrypted', { size: mediaData.length });

        const transcription = await transcribe(mediaData, config.apiKey, config.language);
        logger.info('Transcription complete', { length: transcription.length });

        await client.reply(voiceNote.from, transcription, voiceNote.id);
      } catch (error) {
        logger.error('Transcription failed', { error: errorMessage(error) });
      }
    });
  },
});

Load and test it

Add to your wa.config.js:

// wa.config.js
export default {
  plugins: [
    './plugins/voice-transcriber', // Local path
  ],
  pluginConfig: {
    'voice-transcriber': {
      apiKey: process.env.STT_API_KEY,
      language: 'en',
      enabled: true,
    },
  },
};

Start a named session for testing:

npx @open-wa/wa-automate --session-id dictation-test --port 8080

Send a voice note to your session. The plugin should reply with the transcription. If nothing happens, check that the message is an OGG audio voice note and that STT_API_KEY is set.

What can go wrong

The example catches errors and logs them without crashing:

Decryption failure: Logged, message skipped
API failure: Logged, message skipped
Empty transcription: Still sent (the user may want to know the API heard nothing)

Plugin getting started, build your first plugin
PluginClient reference, available client methods
External API patterns, calling external services
