Anatomy of a Plugin
Step-by-step walkthrough of the webhook and Chatwoot reference plugins.
This page explains the event and lifecycle patterns used by the webhook and Chatwoot integrations in this checkout. Keep the source files as the authority when an integration adds provider-specific behavior.
The Webhook Plugin
The webhook plugin pushes public WhatsApp events to an external HTTP endpoint. It demonstrates catch-all event forwarding, configuration, bounded delivery, retries, and disposal.
File Location
integrations/webhook/src/plugin.tsStructure Breakdown
export default createPlugin({
meta: { name: 'webhook' },
configSchema: webhookConfigSchema,
init: async ({ logger, config, sessionId }) => ({
event: async ({ event, payload }) => {
// The integration's deliverer applies filtering, queueing and retries.
await deliver(event, payload, config, sessionId);
},
dispose: async () => {
// Drain and close the delivery runtime.
},
}),
});Key Patterns
meta.name: Used for logging prefix and config key mappingconfigSchema: Zod schema that validatespluginConfig.webhookfromwa.config.jsinit: Creates the delivery runtime and returns the plugin'sHooksobjectevent: Receives public events; the integration filters and queues the events selected by its configdispose: Releases the delivery runtime and drains its queue during shutdown
Event Forwarding Pattern
event: async ({ event, payload }) => {
await fetch(config.url, {
method: 'POST',
headers: { 'Content-Type': 'application/json' },
body: JSON.stringify({
event,
data: payload,
timestamp: Date.now(),
}),
});
});This is a shape for a simple receiver. The supplied integration adds event filtering, queue capacity, retry policy, request timeouts, and optional durable delivery around the HTTP call.
The Chatwoot Plugin
The Chatwoot plugin bridges WhatsApp into Chatwoot conversations. It demonstrates bidirectional message handling, contact management, and media mapping.
File Location
integrations/chatwoot/src/plugin.tsStructure Breakdown
export default createPlugin({
meta: { name: 'chatwoot' },
configSchema: chatwootConfigSchema,
init: async ({ events, logger, config, client }) => { ... },
});Key Patterns
- Bidirectional sync: WhatsApp messages flow into Chatwoot, and Chatwoot agent replies flow back to WhatsApp
- Contact mapping: Phone numbers are mapped to Chatwoot contacts
- Media handling: Media messages are uploaded to Chatwoot as attachments
Contact Sync Pattern
async function getOrCreateContact(phoneNumber: string) {
// Check if contact exists in Chatwoot
// If not, create a new contact
// Return the contact ID
}Message Routing Pattern
events.on('message.received', async ({ message }) => {
const contactId = await getOrCreateContact(message.from);
await createChatwootMessage(contactId, message.body);
});Patterns to Reuse
1. Config Validation
Always provide a configSchema:
const configSchema = z.object({
url: z.string().url(),
apiKey: z.string().optional(),
enabled: z.boolean().default(true),
});2. Event Subscription
Subscribe to specific events instead of a catch-all subscription:
events.on('message.received', handler);
events.on('client.ready', handler);
events.on('core.stopping', handler);3. Error Handling
Wrap external calls in try-catch and log errors:
try {
await fetchExternalAPI(data);
} catch (error) {
logger.error('External API failed', { error: error.message });
}4. Graceful Degradation
Keep the host alive when an external service fails, but make the retry or persistence policy explicit:
events.on('message.received', async ({ message }) => {
try {
await processMessage(message);
} catch (error) {
logger.error('Processing failed', { error: error.message });
// Add an explicit retry or durable queue if the event must not be lost.
}
});5. Lifecycle Awareness
Handle session state changes:
events.on('core.stopping', async () => {
// Flush queues, save state, close connections
logger.info('Plugin shutting down');
});Related
- Plugin getting started - Build your first plugin
- Hooks reference - Available hooks
- Plugin security model - Security boundaries
