Integrations Overview

open-wa provides several ways to connect WhatsApp to other services. This guide helps you choose the right pattern for your use case.

Decision Tree

Start Here

Ask yourself:

1. Do you want to push events to an existing service? Use webhooks
2. Do you want a full inbox experience? Use Chatwoot or a CRM integration
3. Do you want to build custom logic? Use plugins or SocketClient
4. Do you want AI agents to control WhatsApp? Use MCP

Integration Patterns

Data Flow: WhatsApp to Your Service

Webhook Flow

WhatsApp → open-wa → HTTP POST → Your Service

Messages and events are pushed to your endpoint as JSON payloads.

Plugin Flow

WhatsApp → open-wa → Plugin → External API → Response

Plugins run inside the open-wa process and can call external services directly.

Chatwoot Flow

WhatsApp → open-wa → Chatwoot API → Agent Inbox
Agent Reply → Chatwoot API → open-wa → WhatsApp

Bidirectional sync between WhatsApp and Chatwoot.

Contact and Message Sync

How Contacts Work

When a message arrives, open-wa has access to:

• The sender's phone number (in message.from)
• The sender's display name (if available)
• Group membership information

Message Synchronization

• Incoming messages: Delivered to your integration in real-time
• Outgoing messages: Sent through your integration's API
• Message status: Delivery receipts, read receipts, and typing indicators

Security and Compliance

Data Storage

• open-wa stores session data locally (authentication tokens, browser state)
• Messages are not stored by open-wa unless your integration saves them
• Media is decrypted on demand and not persisted

GDPR Considerations

• You are responsible for handling personal data in messages
• Consider implementing message retention policies
• Document what data your integration stores and why

Data Retention

Implement retention policies in your integration:

• Delete old messages after a set period
• Allow users to request data deletion
• Log only what is necessary for operation

Licensing for Integrations

Licensing follows the exact methods and runtime behavior an integration uses, not just the wrapper name. Webhooks, SocketClient, plugins, MCP, Chatwoot, and proxy workflows can call different parts of the API surface, so check the pricing page and the method-level reference before promising a workflow to a customer.

Choosing Your Path

For Quick Integrations

Start with webhooks:

1. Add @open-wa/integration-webhook to plugins in wa.config.*
2. Point pluginConfig.webhook.url at your service endpoint
3. Handle incoming JSON payloads

For Custom Logic

Use plugins:

1. Install the plugin SDK
2. Build your integration as a plugin
3. Load it via wa.config.js

For Full Inbox

Use Chatwoot:

1. Set up Chatwoot
2. Configure the Chatwoot plugin
3. Connect your WhatsApp session

For AI Agents

Use MCP:

1. Enable MCP in config with mcp: { enabled: true } and keep apiKey configured
2. Verify whether your installed build mounts the configured /mcp route
3. If /mcp is mounted, point your AI client at that endpoint so it can discover and call WhatsApp methods
4. If /mcp is not mounted in your build, give the agent the HTTP API docs, OpenAPI schema, or Postman collection instead
