Chatwoot integration

Use this integration when you want support agents to handle WhatsApp conversations from a Chatwoot inbox. Incoming WhatsApp messages create or reopen Chatwoot conversations. Chatwoot replies return through the connected open-wa session.

The current plugin package is @open-wa/integration-chatwoot@5.1.0. Chatwoot's account and API behavior can vary by self-hosted release, so record the Chatwoot version alongside your deployment runbook and verify the token permissions against that release.

Chatwoot-side setupCopy Anchor Link

Start in Chatwoot before you start the open-wa runtime. The integration can create the API inbox for you, but you still need to know the Chatwoot pieces it expects.

1. Open the Chatwoot account you want WhatsApp conversations to appear in.
2. Create a user access token from your Chatwoot profile settings. The token must be able to create contacts, conversations, messages, and inboxes for the target account.
3. Decide whether open-wa or an administrator will create the inbox.
4. If you create the inbox, create an API inbox. Use the public open-wa webhook URL as the inbox webhook URL.
5. Keep the account ID and inbox ID handy. You can copy them from the Chatwoot URL after opening the account or inbox.

The easiest path is to pass an account URL such as https://app.chatwoot.com/api/v1/accounts/123 and let the plugin create or find the matching API inbox. If you already have an inbox, pass an inbox URL such as https://app.chatwoot.com/api/v1/accounts/123/inboxes/456.

Inbox/webhook configCopy Anchor Link

Use an API inbox in Chatwoot. The webhook URL must point back to the open-wa plugin route:

https://wa.example.com/plugins/chatwoot/webhook?api_key=your-secure-key

The matching Chatwoot inbox values are:

If forceUpdateCwWebhook is true, open-wa patches the inbox webhook URL during startup. Use that when the public API host changes or when you want config to be the source of truth.

Exact open-wa configCopy Anchor Link

Load Chatwoot as a plugin and place the Chatwoot settings under pluginConfig.chatwoot:

Install the plugin in the Easy API project first:

npm install @open-wa/integration-chatwoot@5.1.0
export OPENWA_CALLBACK_KEY='replace-with-a-long-random-value'
export CHATWOOT_API_ACCESS_TOKEN='replace-with-a-Chatwoot-user-token'

const callbackKey = process.env.OPENWA_CALLBACK_KEY?.trim();
const chatwootToken = process.env.CHATWOOT_API_ACCESS_TOKEN;
if (!callbackKey || !chatwootToken) throw new Error('Set the Chatwoot and callback secrets');

export default {
  sessionId: 'sales',
  port: 8080,
  host: '0.0.0.0',
  apiKey: callbackKey,
  plugins: ['@open-wa/integration-chatwoot'],
  pluginConfig: {
    chatwoot: {
      chatwootUrl: 'https://app.chatwoot.com/api/v1/accounts/123',
      chatwootApiAccessToken: chatwootToken,
      apiHost: 'https://wa.example.com',
      apiKey: callbackKey,
      forceUpdateCwWebhook: true,
    },
  },
};

The plugin appends callbackKey as api_key to Chatwoot's webhook URL. The Chatwoot route does not validate it, so configure a reverse proxy or gateway to check the query value before forwarding callbacks.

Save this as wa.config.mjs, then start the matching session:

npx @open-wa/wa-automate@5.1.0 --config ./wa.config.mjs --session-id sales --host 0.0.0.0 --port 8080

If you want to bind the plugin to an existing Chatwoot inbox, include the inbox ID in chatwootUrl:

chatwootUrl: 'https://app.chatwoot.com/api/v1/accounts/123/inboxes/456'

apiHost must be the public origin that Chatwoot can access. Do not include /plugins/chatwoot/webhook. The plugin adds that path.

Media mappingCopy Anchor Link

WhatsApp messages become Chatwoot conversation messages. Text messages are sent as normal Chatwoot messages, and media messages are sent as attachments when open-wa can decrypt the file.

For WhatsApp to Chatwoot:

• image, audio, ptt, video, and document messages are decrypted and uploaded as Chatwoot attachments when media data is available.
• if the WhatsApp message already has a cloudUrl, Chatwoot receives a text message containing the file URL and the message text.
• location messages become a text message with the location label and a Google Maps link.
• button responses use the selected button ID as the message text.

For Chatwoot to WhatsApp:

• plain Chatwoot replies are sent with sendText.
• replies containing a URL are sent with link preview support.
• replies beginning with a location token like @51.5072,-0.1276 Meeting point are sent as WhatsApp locations.
• Chatwoot attachments are sent to WhatsApp as images with the Chatwoot message content as the first caption.

The plugin marks outbound WhatsApp message IDs as ignored so the same message does not loop back into Chatwoot as a new inbound message.

Contact syncCopy Anchor Link

When a WhatsApp message arrives, the plugin looks for a Chatwoot contact with the WhatsApp phone number. If no contact exists and the message includes contact metadata, it creates one.

Created contacts use:

• the WhatsApp ID as the Chatwoot identifier
• the best available display name from WhatsApp contact metadata
• the phone number in +<number> format
• the WhatsApp profile thumbnail URL as avatar_url when available
• a custom attribute named wa:number

The plugin keeps an in-memory contact registry and conversation registry while the process is running. For each contact, it reuses an open conversation in the configured inbox when possible, reopens an existing conversation when needed, or creates a new conversation.

Runbook capture checklistCopy Anchor Link

This guide uses a capture checklist rather than fabricated product screenshots. Chatwoot menus and labels vary across hosted and self-hosted releases, so capture these redacted states from the Chatwoot version you deploy and keep the version beside each image in your private runbook:

• Account and token: the account URL with the numeric account ID visible, while the access token and personal details are masked.
• API inbox: the inbox type, name, phone number, and account or inbox ID, with private customer data removed.
• Webhook callback: the inbox channel configuration showing /plugins/chatwoot/webhook and the redacted callback key boundary.
• Incoming message: an open or reopened conversation containing one redacted WhatsApp message and its timestamp.
• Agent reply: the same conversation after a plain text reply reaches WhatsApp, with customer and message content masked.
• Attachment path: one supported attachment state, or the visible file-link result when the inbound media has only cloudUrl and cannot be decrypted by open-wa.

These captures document the UI state your deployment reached; they do not prove that a different Chatwoot release has the same labels or that webhook authentication is enforced by the open-wa router. Keep the source version, account identifiers, access tokens, phone numbers, and message bodies out of published screenshots.

Verify the integrationCopy Anchor Link

Use these observable checks after configuration. They give you a useful success or failure record without relying on screenshots or asking you to create documentation artifacts.

1. Confirm the Chatwoot token and account. Run curl -i -H "api_access_token: $CHATWOOT_API_ACCESS_TOKEN" "$CHATWOOT_ORIGIN/api/v1/profile". Expect 200 and a JSON account_id. If you receive 401, create a new user access token or correct chatwootUrl; open-wa cannot create or find an inbox until this request succeeds.
2. Confirm the open-wa process initialized the integration. Start the runtime and look for Chatwoot integration initialized. If the log instead contains CW REQ ERROR or a non-2xx CW REQUEST, compare chatwootUrl, the token header, and the account/inbox ID parsed from the URL. The plugin uses api_access_token on requests to Chatwoot.
3. Confirm the inbox and callback value. In Chatwoot, open the API inbox and read its channel webhook URL. It should be https://wa.example.com/plugins/chatwoot/webhook?api_key=your-secure-key when apiHost and apiKey are configured. forceUpdateCwWebhook: true makes open-wa PATCH this value during startup; otherwise an existing inbox keeps its current URL.
4. Understand the callback key boundary. The plugin appends api_key to the URL, and the Easy API's shared API-key middleware accepts X-API-Key, api_key, or key on the API routes. The current Chatwoot Hono router itself parses the query but does not validate api_key; if the callback must be authenticated, put a reverse proxy or gateway in front of /plugins/chatwoot/webhook that checks the query value (or an equivalent header) before forwarding it. A Chatwoot 200 response alone is not proof that this boundary is protected.
5. Verify WhatsApp to Chatwoot. Send a direct WhatsApp message to the connected number, then inspect Chatwoot. Expect a contact, an open or reopened conversation, and an incoming message. The plugin ignores group and broadcast messages; check message.from, the session connection state, and the token's contact/conversation permissions when nothing appears.
6. Verify Chatwoot to WhatsApp. Send a plain reply from that conversation. Chatwoot must POST an event with event: "message_created", a non-private message, and a sender phone number. Expect the plugin response to contain a WhatsApp message ID and the recipient to receive the text. A private note, incoming message echo, missing phone number, or different event is intentionally ignored.
7. Verify media and special formats when they matter. Send one attachment, one URL, and one location-formatted reply. Expect attachments to use sendImage, URLs to use link preview, and a leading token such as @51.5072,-0.1276 Meeting point to use sendLocation. If only cloudUrl is available on an inbound media message, expect a file link in Chatwoot rather than an uploaded attachment.

TroubleshootingCopy Anchor Link

• No inbox appears: confirm chatwootUrl contains the right account ID and that the Chatwoot token can manage inboxes.
• Webhook URL is wrong: set apiHost to the public open-wa origin and set forceUpdateCwWebhook: true for one startup.
• Chatwoot replies do not arrive in WhatsApp: Confirm Chatwoot can POST to https://wa.example.com/plugins/chatwoot/webhook?api_key=your-secure-key, then inspect the open-wa log for Webhook processing error. The plugin expects message_created, a non-private message, a sender phone number, and a connected session. If a reverse proxy checks the query key, make sure its value matches the proxy configuration; the Chatwoot router does not enforce that query value itself.
• WhatsApp messages do not appear in Chatwoot: Make sure that the WhatsApp session is connected. Make sure that the message is not from a group or broadcast chat. Make sure that the Chatwoot token can create contacts and conversations.
• Media does not appear as an attachment: confirm open-wa can decrypt the media. If the message has only a cloudUrl, Chatwoot receives a file link instead of an uploaded attachment.
• Duplicate messages appear: check for multiple open-wa runtimes connected to the same WhatsApp account or multiple Chatwoot inboxes pointing to the same webhook.
• Location replies are sent as text: use the expected location format at the start of the Chatwoot reply, for example @51.5072,-0.1276 Meeting point.
