Proxying a session

If your environment requires outbound traffic to pass through a proxy, set proxyServerCredentials in your config.

await create({
  proxyServerCredentials: {
    address: 'http://proxy.example:1234',
    username: 'open-wa',
    password: 'secret',
  },
});

Proxy URL formats

The proxy address must include the protocol. Supported formats are:

http://proxy.example:1234
https://proxy.example:1234
socks://proxy.example:1080
socks5://proxy.example:1080

Use the exact scheme your proxy provider gives you. If the proxy needs a username and password, keep those in username and password instead of embedding them in the URL.

SOCKS/HTTP

Use an HTTP or HTTPS proxy when your provider is forwarding normal web traffic and gives you an HTTP endpoint. This is the most common setup for data center, residential, and corporate outbound proxies.

Use a SOCKS or SOCKS5 proxy when your provider gives you a lower-level tunnel endpoint, or when HTTP proxying breaks WebSocket or browser network behavior in your environment.

If both are available, start with http:// or https://. Switch to socks5:// when your provider recommends it or when browser authentication, media, or WebSocket paths fail through the HTTP proxy.

Env-secret

Keep proxy credentials out of checked-in config files. Read them from environment variables and pass them into proxyServerCredentials at startup:

await create({
  proxyServerCredentials: {
    address: process.env.OPENWA_PROXY_ADDRESS,
    username: process.env.OPENWA_PROXY_USERNAME,
    password: process.env.OPENWA_PROXY_PASSWORD,
  },
});

Example local shell setup:

export OPENWA_PROXY_ADDRESS="http://proxy.example:1234"
export OPENWA_PROXY_USERNAME="open-wa"
export OPENWA_PROXY_PASSWORD="secret"

If your deployment platform has a secret manager, store these values there and inject them as environment variables at runtime.

Docker/prod

For Docker, pass the proxy settings as environment variables and keep the same runtime config shape in your app:

docker run --init \
  -e OPENWA_PROXY_ADDRESS="http://proxy.example:1234" \
  -e OPENWA_PROXY_USERNAME="open-wa" \
  -e OPENWA_PROXY_PASSWORD="secret" \
  openwa/wa-automate

In production, make the proxy part of your session configuration rather than a manual shell-only step. Confirm the runtime host can reach the proxy before starting a long-lived session, and use separate proxy credentials per environment when possible.

For orchestrated deployments, set the same variables in your platform config:

env:
  OPENWA_PROXY_ADDRESS: http://proxy.example:1234
  OPENWA_PROXY_USERNAME: open-wa
  OPENWA_PROXY_PASSWORD: secret

Use your orchestrator's secret support for the username and password instead of storing real values in plain YAML.

Auth caveats

Proxy authentication is separate from open-wa API authentication. proxyServerCredentials.username and proxyServerCredentials.password are only for the outbound proxy.

Some proxy providers require IP allowlisting instead of username/password auth. In that case, leave username and password unset and make sure the host running open-wa is allowlisted by the provider.

Avoid putting proxy credentials directly in the proxy URL. Keeping the address, username, and password separate makes logs safer and avoids URL parsing issues with special characters in passwords.

Test the proxy during the first WhatsApp authentication flow. A proxy can appear healthy after login but still fail during QR, link-code, media upload, or WebSocket reconnect paths.

Verification commands

Check that the proxy itself works from the same host that runs open-wa:

curl -x "http://proxy.example:1234" \
  --proxy-user "$OPENWA_PROXY_USERNAME:$OPENWA_PROXY_PASSWORD" \
  https://api.ipify.org

For a SOCKS5 proxy:

curl --socks5-hostname "proxy.example:1080" https://api.ipify.org

If your proxy uses IP allowlisting and no username/password:

curl -x "http://proxy.example:1234" https://api.ipify.org

The returned IP should match the proxy exit IP, not the server's normal public IP.

Then start a session and verify the parts most likely to expose proxy issues:

• complete the first authentication flow
• reconnect after restarting the process
• send and receive a text message
• upload and download media
• watch for WebSocket or navigation errors in the runtime logs

When to use this page

Use this when you need a traditional outbound proxy for the automation runtime itself.

If what you actually want is remote consumer access to a running session without opening inbound ports, use Cloudflare Session Proxy instead.

Tips

• Keep proxy credentials in environment variables or a secure secret store.
• Validate proxy behavior during authentication flows, not only after the session is already healthy.
• Test media upload/download paths explicitly, because those tend to surface proxy issues first.
