Socket Client

SocketClient is the compatibility client for connecting to a remote Easy API instance. In the current runtime it uses HTTP RPC for commands and Server-Sent Events for runtime events, while keeping a client-style surface for consumers.

Install command

Install the remote consumer package in the app that will connect to Easy API:

npm install @open-wa/socket-client

pnpm add @open-wa/socket-client

Connect to a local or remote Easy API

import { SocketClient } from '@open-wa/socket-client';

const client = await SocketClient.connect('http://localhost:8080', 'your-api-key');

The client surface exposes direct methods such as sendText(...), and you can also use ask(...) / listen(...) when you want the explicit transport-level style.

Authentication

If your Easy API instance is protected with an API key, pass it when connecting:

const client = await SocketClient.connect('https://api.example.com', 'your-api-key');

Keep the API key out of browser-exposed code unless that browser is a trusted internal client.

API key headers

Pass the API key as the second argument to SocketClient.connect():

const client = await SocketClient.connect('https://api.example.com', 'your-api-key');

For command calls, SocketClient sends that key to Easy API as the X-API-Key header:

X-API-Key: your-api-key

For the SSE event stream, the same key is attached to the events URL as api_key because the standard EventSource API does not support custom headers.

Full runnable consumer

Create a consumer file in your own app, for example consumer.ts:

import { SocketClient, type Client } from '@open-wa/socket-client';

const EASY_API_URL = process.env.OPENWA_API_URL ?? 'http://localhost:8080';
const API_KEY = process.env.OPENWA_API_KEY ?? 'your-api-key';
const TEST_CHAT_ID = process.env.OPENWA_TEST_CHAT_ID ?? '1234567890@c.us';

async function main() {
  const client = await SocketClient.connect(EASY_API_URL, API_KEY) as SocketClient & Client;

  client.socket.on('connect', () => {
    console.log('Connected to Easy API event stream');
  });

  client.socket.on('disconnect', (reason) => {
    console.warn('Easy API event stream disconnected:', reason);
  });

  client.socket.on('connect_error', (error) => {
    console.error('Could not connect to Easy API events:', error);
  });

  await client.listen('onMessage', async (message) => {
    try {
      console.log('Incoming message:', message.from, message.body);

      if (message.body?.toLowerCase() === 'ping') {
        await client.sendText(message.from, 'pong');
      }
    } catch (error) {
      console.error('Failed to handle incoming message:', error);
    }
  });

  try {
    const sent = await client.sendText(TEST_CHAT_ID, 'SocketClient consumer is online');
    console.log('Startup message sent:', sent);
  } catch (error) {
    console.error('Failed to send startup message:', error);
  }

  process.once('SIGINT', () => {
    client.close();
    process.exit(0);
  });
}

main().catch((error) => {
  console.error('SocketClient consumer failed to start:', error);
  process.exit(1);
});

Run it with your own Easy API URL, API key, and test chat ID:

OPENWA_API_URL="http://localhost:8080" \
OPENWA_API_KEY="your-api-key" \
OPENWA_TEST_CHAT_ID="1234567890@c.us" \
npx tsx consumer.ts

Send a command

await client.sendText('1234567890@c.us', 'Hello from SocketClient');

// explicit RPC style also works
await client.ask('sendText', {
  to: '1234567890@c.us',
  content: 'Hello from SocketClient',
});

Listen to events

client.onMessage((message) => {
  console.log(message.body);
});

await client.listen('onMessage', (message) => {
  console.log(message.body);
});

Legacy-style listener helpers are mapped onto the active runtime event stream for you, so you can usually keep familiar event names.

Lifecycle/reconnect

SocketClient.connect() waits until the SSE event stream is open before it resolves. After that, commands are sent over HTTP RPC and events arrive over the same SSE stream.

Useful lifecycle hooks are available through client.socket:

client.socket.on('connect', () => {
  console.log('event stream connected');
});

client.socket.on('disconnect', (reason) => {
  console.log('event stream disconnected:', reason);
});

client.socket.on('connect_error', (error) => {
  console.error('event stream connection failed:', error);
});

The underlying EventSource implementation handles normal SSE reconnects automatically. Listener registrations are kept locally and are bound again when the stream opens. You can also force a reconnect yourself:

await client.reconnect();

Call client.close() or client.disconnect() when your process is shutting down.

SSE failure

If the SSE connection drops after it was connected, SocketClient marks client.socket.connected as false and emits disconnect with the reason eventsource error. Commands can still fail or succeed independently because they use HTTP RPC, so wrap command calls in try / catch.

If the first SSE connection cannot be established, SocketClient.connect() rejects with an Unable to establish SSE connection error and emits connect_error.

try {
  const client = await SocketClient.connect('http://localhost:8080', 'your-api-key');

  client.socket.on('disconnect', async () => {
    try {
      await client.reconnect();
    } catch (error) {
      console.error('Manual reconnect failed:', error);
    }
  });
} catch (error) {
  console.error('Could not connect to Easy API:', error);
}

In most cases you only need to listen for disconnect and keep your consumer idempotent. Avoid assuming every dropped event stream means the WhatsApp session itself is dead. Check the Easy API session health before restarting the runtime.

Cloudflare proxy URLs

SocketClient.connect() also understands cf-proxy://... URLs for the Cloudflare tunnel flow described in Cloudflare Session Proxy.

When to use it

Use SocketClient when:

• your automation runtime lives on another machine
• you want a lightweight consumer app instead of embedding the full browser automation runtime
• you want to connect dashboards, workers, or services to an Easy API instance

Compatibility

This @open-wa/socket-client page describes the current Easy API transport used by the v5 runtime: HTTP RPC for commands and SSE for events. It is intended for Easy API instances that expose /api/{method} command routes and /api/events for the event stream.

Older v4 deployments and older socket.io-based examples may not match this transport. If you are running the stable v4 line, use the SocketClient version and docs that match that deployment. If you are testing v5 alpha, keep Easy API and @open-wa/socket-client on matching current packages from this repo.

Browser security

SocketClient does not give your app browser access. It only gives your app API access to a running Easy API instance.

That means your consumer can call exposed Easy API methods and receive events, but it cannot inspect the browser page, run browser-side code, or bypass the Easy API security boundary. Treat the API key like a server secret.

Plugin SocketClient guidance

Plugins that run outside the Easy API process can use SocketClient to connect back to a local Easy API instance. This is useful when the plugin is packaged as a separate worker, sidecar, or integration service and should not own the WhatsApp browser runtime.

import { SocketClient } from '@open-wa/socket-client';

export async function startPluginConsumer() {
  const client = await SocketClient.connect(
    process.env.OPENWA_API_URL ?? 'http://localhost:8080',
    process.env.OPENWA_API_KEY
  );

  await client.listen('onMessage', async (message) => {
    // plugin-specific integration logic
    console.log('plugin saw message:', message.id);
  });

  return client;
}

Keep the Easy API URL and API key in plugin configuration or environment variables. Do not hard-code local secrets into a published plugin package.

Troubleshooting

• Verify the base URL first; include the protocol and the correct port.
• If events do not appear, confirm the target Easy API session is actually healthy before debugging the consumer.
• If auth is enabled, verify the same API key that works over HTTP is the one you are passing to SocketClient.connect().
• If you need remote access without opening ports, prefer the Cloudflare proxy route instead of inventing your own transport bridge.
