Event Reference

Open-WA uses a centralized event system based on HyperEmitter. You can listen to these events to react to WhatsApp messages, connection state changes, and internal runtime lifecycle steps.

Listener examples

Import the shared emitter when you need process-level lifecycle events:

import { ev } from '@open-wa/wa-automate';

Listen for common runtime and WhatsApp activity events by name:

ev.on('client.ready', ({ sessionId }) => {
  console.log(`Session ${sessionId} is ready`);
});

ev.on('message.received', async ({ message, ctx }) => {
  console.log('Message received', ctx.correlationId, message);
});

ev.on('session.connection.disconnected', ({ details }) => {
  console.warn('Session disconnected', details?.reason);
});

ev.on('error', ({ scope, error, fatal }) => {
  console.error(`Open-WA error in ${scope}`, { fatal, error });
});

Use client-level helpers, such as client.onMessage, for normal bot behavior after the client is ready. Use ev when you need startup, auth, disconnect, webhook, persistence, or internal runtime events.

Wildcard example

The shared emitter supports wildcard listeners. This is useful for debugging or for carefully redacted audit sinks. Some compatibility and session-level emitters also pass session data through wildcard segments:

ev.on('**.**', (payload, sessionId, namespace) => {
  auditEvent({
    namespace,
    sessionId,
    receivedAt: Date.now(),
  });
});

Keep wildcard listeners narrow in production. QR codes, link codes, session artifacts, and persistence events can contain sensitive data.

OpenWAEventMap

This interface defines all available events and their corresponding payload shapes.

Full event names

The table below lists every event name in OpenWAEventMap with its namespace. Event names without a dot are process-level compatibility or utility events.

Payload samples

The generated table above is the source of truth for payload shapes. These samples show the structure you will usually see in logs or listeners.

client.ready

{
  "sessionId": "sales"
}

message.received

{
  "ctx": {
    "correlationId": "evt_01HX9Q8K7V3P",
    "ts": 1715683200000
  },
  "message": {
    "id": "true_447700900123@c.us_3EB0F",
    "from": "447700900123@c.us",
    "body": "Hi"
  }
}

launch.auth.qr.generated

{
  "correlationId": "launch_01HX9Q8K7V3P",
  "attempt": 1,
  "ts": 1715683200000,
  "step": "launch.auth.qr.generated",
  "details": {
    "qr": "2@abc...",
    "ascii": "████ QR ████",
    "attemptInThisCycle": 1
  }
}

session.connection.disconnected

{
  "correlationId": "session_01HX9Q8K7V3P",
  "ts": 1715683300000,
  "step": "session.connection.disconnected",
  "details": {
    "reason": "browser_closed",
    "wasLoggedIn": true
  }
}

webhook.trigger.after

{
  "ctx": {
    "correlationId": "webhook_01HX9Q8K7V3P",
    "ts": 1715683400000
  },
  "webhookId": "primary-crm",
  "event": "message.received",
  "enqueued": true
}

Lifecycle ordering

A normal first login usually follows this order:

1. core.starting
2. launch.create.start
3. launch.config.setup.before
4. launch.config.setup.after
5. launch.browser.init.before
6. launch.browser.init.after
7. launch.page.init.before
8. launch.page.init.after
9. launch.navigation.gotoWaWeb.before
10. launch.navigation.gotoWaWeb.after
11. launch.auth.check.before
12. launch.auth.qr.generated, when a new login needs a QR
13. launch.auth.qr.scanned, after the QR is scanned
14. launch.auth.check.after, when auth state is known
15. launch.wapi.inject.before
16. launch.wapi.inject.after
17. launch.session.validityCheck.before
18. launch.session.validityCheck.after
19. launch.client.finalize.before
20. launch.client.finalize.after
21. session.state.changed, usually to READY
22. client.ready
23. core.started

Warm starts can skip QR events. Failed starts may emit retry, timeout, invalid session, or error events before the lifecycle reaches client.ready.

Mapping to session-events guide

This reference lists the typed event names and payloads from the core event map. For a task-oriented guide to QR capture, session data handling, lifecycle timing, and wildcard patterns, read Session events.

Common Payloads

StepEvent

Most internal launch and lifecycle events use the StepEvent wrapper.

EventContext

Standard metadata included with almost every event.
