Messaging Reference

The Message object is the most common data structure in Open-WA. It contains all information about a WhatsApp message, including content, sender, and media metadata.

Message

The core message structure used in events and method returns.

Prop

Type

Chat

Represents a WhatsApp chat session (individual or group).

Prop

Type

Contact

Represents a WhatsApp contact, either a single user or a participant in a group.

Prop

Type

Real examples of Message/Chat/Contact

These examples show common runtime shapes. WhatsApp can add extra fields, so store the fields you need and treat the payload as extensible.

Message example

A text message includes routing fields, sender details, chat details, direction, timestamps, and message state.

{
  "id": "false_447700900000@c.us_3EB0A1B2C3D4E5F67890",
  "body": "Hi, is my order ready?",
  "type": "chat",
  "t": 1768848000,
  "timestamp": 1768848000,
  "from": "447700900000@c.us",
  "to": "15551234567@c.us",
  "chatId": "447700900000@c.us",
  "fromMe": false,
  "self": "in",
  "ack": 1,
  "isGroupMsg": false,
  "isMedia": false,
  "isNotification": false,
  "isQuotedMsgAvailable": false,
  "sender": {
    "id": "447700900000@c.us",
    "pushname": "Aisha",
    "isMyContact": true,
    "isWAContact": true
  },
  "chat": {
    "id": "447700900000@c.us",
    "name": "Aisha",
    "isGroup": false,
    "unreadCount": 1,
    "contact": {
      "id": "447700900000@c.us",
      "pushname": "Aisha",
      "isWAContact": true
    }
  }
}

Chat example

A one-to-one chat usually points at the contact chat ID. A group chat uses an @g.us ID and may include groupMetadata.

{
  "id": "447700900000@c.us",
  "name": "Aisha",
  "formattedTitle": "Aisha",
  "isGroup": false,
  "unreadCount": 1,
  "t": 1768848000,
  "contact": {
    "id": "447700900000@c.us",
    "pushname": "Aisha",
    "isMyContact": true,
    "isWAContact": true
  },
  "msgs": []
}

Contact example

Contact display fields are optional. Use id as the stable identity for lookups and message targets.

{
  "id": "447700900000@c.us",
  "name": "Aisha Khan",
  "shortName": "Aisha",
  "pushname": "Aisha",
  "formattedName": "Aisha Khan",
  "isBusiness": false,
  "isEnterprise": false,
  "isMe": false,
  "isMyContact": true,
  "isUser": true,
  "isWAContact": true,
  "labels": [],
  "profilePicThumbObj": {
    "eurl": "https://mmg.whatsapp.net/...",
    "img": "https://mmg.whatsapp.net/...",
    "tag": "profile-thumb"
  }
}

Message Content Types

Media message

Media messages are still Message objects. The type field identifies the media kind, and isMedia is the safest first check before downloading or decrypting content.

{
  "id": "false_447700900000@c.us_3EB09988776655443322",
  "body": null,
  "caption": "Receipt from today",
  "type": "image",
  "mimetype": "image/jpeg",
  "t": 1768848240,
  "timestamp": 1768848240,
  "from": "447700900000@c.us",
  "to": "15551234567@c.us",
  "chatId": "447700900000@c.us",
  "fromMe": false,
  "self": "in",
  "ack": 1,
  "isGroupMsg": false,
  "isMedia": true,
  "isMMS": true,
  "isNotification": false,
  "isQuotedMsgAvailable": false,
  "clientUrl": "https://mmg.whatsapp.net/...",
  "deprecatedMms3Url": "https://mmg.whatsapp.net/...",
  "mediaData": {
    "type": "image",
    "mediaStage": "RESOLVED",
    "mimetype": "image/jpeg",
    "filehash": "8f2b5f7b4c0a1d2e3f4a5b6c7d8e9f00",
    "size": 248391
  }
}

Common media fields include:

Field	Meaning
`type`	Message type, such as `image`, `video`, `audio`, `ptt`, `document`, or `sticker`.
`isMedia` / `isMMS`	Flags that mark messages with downloadable media metadata.
`mimetype`	MIME type for the encrypted media, such as `image/jpeg` or `application/pdf`.
`caption`	Optional text attached to image, video, or document messages.
`mediaData`	Runtime metadata used to locate and decrypt encrypted media.
`clientUrl` / `deprecatedMms3Url`	Media URLs that may appear on some payloads. Treat them as runtime details.

Do not read file bytes from body. Use caption for attached text and pass the message to media helpers when you need the content.

Location

Geographical data associated with location messages.

Prop

Type

Location message

A location message is a Message object with type: "location". Depending on the runtime version, coordinates may appear directly on the message or inside a location-shaped field.

{
  "id": "false_447700900000@c.us_3EB01234ABCD5678EF90",
  "body": "Shared location",
  "type": "location",
  "t": 1768848360,
  "timestamp": 1768848360,
  "from": "447700900000@c.us",
  "to": "15551234567@c.us",
  "chatId": "447700900000@c.us",
  "fromMe": false,
  "self": "in",
  "ack": 1,
  "isGroupMsg": false,
  "isMedia": false,
  "isNotification": false,
  "isQuotedMsgAvailable": false,
  "lat": 51.5074,
  "lng": -0.1278,
  "loc": "London",
  "clientUrl": "https://maps.google.com/?q=51.5074,-0.1278",
  "sender": {
    "id": "447700900000@c.us",
    "pushname": "Aisha"
  }
}

The normalized Location shape uses these fields:

{
  "lat": 51.5074,
  "lng": -0.1278,
  "name": "London",
  "address": "London, UK",
  "url": "https://maps.google.com/?q=51.5074,-0.1278"
}

Field caveats

The generated tables describe the common contract, but live WhatsApp payloads vary by message type, account state, and runtime version.

Field	Caveat
`body`	Usually text for `chat` messages. It can be empty or null for media, location, notification, revoked, or system messages.
`caption`	Only appears when the sender included caption text on supported media types.
`sender`, `chat`, `quotedMsg`, `quotedMsgObj`	Nested objects can be partial snapshots. Quote fields only appear when WhatsApp still exposes the quoted message.
`author` / `senderId`	Most useful in groups. They can be absent in one-to-one messages or older payloads.
`notifyName`, `name`, `pushname`, `formattedName`	Display names depend on what the session knows about the contact. Do not use them as stable IDs.
`mimetype`, `mediaData`, `clientUrl`, `deprecatedMms3Url`	Media-only runtime fields. Some versions expose one URL field, both URL fields, or neither.
`lat`, `lng`, `loc`, `name`, `address`, `url`	Location fields differ across raw message payloads and normalized location objects. Check both direct message fields and location-shaped data when handling older payloads.
Extra fields	The schemas use passthrough objects, so additional WhatsApp or driver fields may be present. Preserve unknown fields if your workflow needs full fidelity.
