Core Client Reference

The core client is the primary interface for interacting with WhatsApp. Use these tables to explore the available methods, properties, and configuration options.

create vs createClient vs Easy API vs OpenWAClient relationship

Open-WA exposes a few entry points because each one owns a different layer of the runtime.

Entry point	What it is	Use it when
Easy API	The hosted HTTP API and dashboard started by the CLI or API server.	You want the fastest path to a running WhatsApp API, generated docs, webhooks, or MCP tools.
`createClient`	The low-level core factory exported from `@open-wa/core` and re-exported by `@open-wa/wa-automate`.	You want to own the browser driver, startup lifecycle, events, plugins, and shutdown inside your own Node.js process.
`create`	A convenience runtime helper that resolves Open-WA config, chooses a driver, and then calls core `createClient`.	You want programmatic startup with config-style defaults instead of building a full `CreateClientOptions` object yourself.
`OpenWAClient`	The object returned by `createClient`.	You already created a core runtime and need to start it, stop it, inspect readiness, access events, or reach the transport.

Think of Easy API as the packaged service, create as a config-aware helper, createClient as the core constructor, and OpenWAClient as the running runtime handle. The higher-level client facade and socket clients build on top of those pieces to expose familiar message methods. The core client itself focuses on lifecycle, event flow, plugin hosting, session readiness, and browser transport access.

For most applications, start with Easy API. Use createClient when runtime ownership matters more than convenience, for example when you need a specific driver, custom plugin registration, direct readiness checks, or controlled shutdown behavior.

Runnable example

This example starts the core runtime directly with the Puppeteer driver, listens for lifecycle and message events, prints the readiness snapshot, and shuts down cleanly on process signals.

npm install @open-wa/wa-automate @open-wa/driver-puppeteer

import { createClient } from '@open-wa/wa-automate';
import { PuppeteerDriver } from '@open-wa/driver-puppeteer';

async function main() {
  const client = await createClient({
    sessionId: 'core-example',
    driver: new PuppeteerDriver(),
    headless: true,
    qrTimeoutMs: 0,
  });

  client.events.on('core.starting', () => {
    client.logger.info('Core runtime is starting');
  });

  client.events.on('client.ready', ({ sessionId }) => {
    client.logger.info('WhatsApp session is ready', { sessionId });
  });

  client.events.on('message.received', ({ message }) => {
    client.logger.info('Received message', { message });
  });

  const stop = async (reason: string) => {
    await client.stop(reason);
    process.exit(0);
  };

  process.once('SIGINT', () => void stop('SIGINT'));
  process.once('SIGTERM', () => void stop('SIGTERM'));

  await client.start();

  console.log('state:', client.getState());
  console.log('readiness:', client.getReadiness());
}

main().catch((error) => {
  console.error(error);
  process.exit(1);
});

The first run will need authentication. After the session reaches READY, getReadiness() should report ready: true and exposureSafe: true.

Lifecycle

The core lifecycle is explicit. createClient(options) builds the runtime object, but it does not connect to WhatsApp until you call client.start().

Method or state	Meaning
`createClient(options)`	Creates the event bus, session manager, transport, plugin host, and plugin client proxy.
`client.start()`	Initializes the driver, opens WhatsApp Web, injects WAPI, waits for authentication, applies patches and license checks, activates runtime events, runs finalization hooks, then emits readiness events.
`client.stop(reason?)`	Moves the session to `STOPPED`, disposes plugins, closes the transport, and emits shutdown events.
`client.getState()`	Returns the current core state.
`client.getReadiness()`	Returns the readiness snapshot used to decide whether the session is safe to expose.
`client.registerFinalizationHook(hook)`	Registers work that must run during the loaded-equivalent finalization phase before the session is marked ready.
`client.getTransport()`	Returns the underlying transport for lower-level runtime access.
`client.screenshot()`	Captures a page screenshot when the active driver supports it.
`client.evaluateScript(script)`	Runs JavaScript in the WhatsApp Web page context and returns the result.

Core session states are intentionally small:

State	Meaning
`DISCONNECTED`	Initial or failed state before the runtime is usable.
`STARTING`	Startup has begun and runtime readiness is being reset.
`AUTHENTICATING`	WhatsApp Web is loaded and authentication is in progress.
`READY`	Runtime validation, patch lifecycle, license lifecycle, and finalization have completed safely.
`STOPPED`	The runtime has been shut down by `client.stop()`.

Readiness is stricter than state. A client can be past authentication but still not safe to expose if runtime validation, patch handling, license handling, finalization, or lower-level transport truth is still pending. Check getReadiness().ready for the simple answer, and inspect pending, blockers, and requirements when you need to explain why a session is not ready yet.

CreateClientOptions

Options passed to the createClient function to initialize the runtime.

Prop

Type

OpenWAClient

The main client interface returned by createClient.

Prop

@open-wa/plugin-sdk is the package plugin authors should import from. Core consumes the same contracts when it registers plugins and builds the filtered plugin runtime.

Export	Kind	Relationship to core
`createPlugin`	Factory	Creates a typed `Plugin` object that core can register through `plugins` or `pluginRefs`.
`CreatePluginOptions`	Type	Describes the object accepted by `createPlugin`, including `meta`, optional `configSchema`, and `init`.
`defineConfig`	Helper	Builds a Zod config schema that core uses to validate `pluginConfig` before plugin initialization.
`z`	Re-export	Lets plugin authors define config schemas without importing Zod separately.
`Plugin`	Type	The callable plugin contract accepted by core.
`PluginMeta`	Type	Metadata core uses for config lookup, route names, logs, and dashboard manifests.
`PluginInput`	Type	The scoped input bundle core passes to a plugin at registration time.
`Hooks`	Type	The event, route, page, tool, and cleanup hooks core wires into the runtime.
`PluginClient`	Type	The safe client proxy core gives to plugins for WhatsApp method calls.
`PluginEventEmitter`	Type	The public-only event subscription surface core gives to plugins.
`PluginLogger`	Type	The scoped logger core gives to each plugin.
`DashboardPage`	Type	Dashboard declarations collected by the core plugin host.
`ToolDefinition`	Type	Plugin tool contract used by automation and AI surfaces.
`ToolContext`	Type	Context core passes when plugin tools execute.
`PluginManifest`	Type	Runtime manifest shape for listing installed plugin capabilities.
`PluginManifestEntry`	Type	One plugin record inside a manifest.

Core also exports PluginHost, createEventGateway, getPublicEvents, loadPlugins, validatePluginConfig, and LoadedPlugin from its plugin module. Those are host-side infrastructure pieces. Plugin packages usually do not need them unless they are building runtime integrations rather than ordinary plugins.
