Configuration and CLI

Use this page to choose runtime settings, CLI flags, environment variables, and plugin configuration that match the way you start open-wa.

Common config fieldsCopy Anchor Link

Use the config object passed to createClient() or exported from wa.config.* for library/runtime behavior such as:

• sessionId: stable session naming
• userDataDir: persistent browser profile directory
• headless: visible vs background browser
• useChrome / executablePath: browser selection
• qrTimeout / authTimeout: authentication timing
• maxQr: limit QR emission count
• cacheEnabled: page/runtime memory trade-off
• licenseKey: feature unlocks where applicable
• proxyServerCredentials: outbound proxy support
• linkCode: link-code login for embedded createClient applications

Full Configuration ReferenceCopy Anchor Link

The reference below lists supported configuration fields, types, defaults, and descriptions.

ExampleCopy Anchor Link

import { createClient } from '@open-wa/wa-automate';

const client = await createClient({
  sessionId: 'sales',
  useChrome: true,
  headless: true,
  qrTimeout: 0,
  authTimeout: 60,
});

Config file discoveryCopy Anchor Link

The CLI loads configuration through the shared config package before applying CLI overrides. By default, discovery starts from the current working directory.

Discovery order is:

1. The wa key in package.json
2. wa.config.js
3. wa.config.cjs
4. wa.config.mjs
5. wa.config.ts
6. wa.config.mts
7. wa.config.cts
8. wa.config.json
9. .warc
10. .warc.json
11. cli.config.js legacy compatibility
12. cli.config.json legacy compatibility

The first matching file wins. Use --config ./path/to/config when you want to load a specific file instead of relying on discovery.

The config loader merges values in this order:

1. schema defaults
2. config file
3. WA_* environment variables
4. CLI flags
5. programmatic overrides, mainly for tests and embedding

The config loader replaces arrays instead of concatenating them. A later plugins value replaces the earlier value.

Config files can export a plain object or a function that returns an object. The config loader supports TypeScript config files.

JSON/TS examplesCopy Anchor Link

These config fields are available to embedded createClient applications. In the published Easy API CLI 5.1.0, startup applies host: 0.0.0.0 and port: 8002 after config and environment loading, so pass --host and --port explicitly when starting the CLI.

{
  "sessionId": "sales",
  "port": 8080,
  "host": "0.0.0.0",
  "apiKey": "replace-with-env-in-production",
  "headless": true,
  "qrTimeout": 0,
  "authTimeout": 60,
  "licenseKey": "YOUR-LICENSE-KEY"
}

Env varsCopy Anchor Link

Supply runtime config with WA_* environment variables. The loader converts snake-case names to config keys. For example, WA_SESSION_ID becomes sessionId.

The config loader converts values when possible:

• true, 1, yes, and on become true
• false, 0, no, and off become false
• numeric strings become numbers for numeric schema fields
• the loader parses JSON values such as {...} or [...] for object and array fields

Common runtime environment variables:

There are also compatibility aliases for a few browser-related settings, including WA_DEBUG for devtools, WA_BROWSER_WS_ENDPOINT for browserWSEndpoint, WA_BYPASS_CSP for bypassCSP, and WA_USE_LIGHTPANDA for useLightpanda.

High-value CLI flagsCopy Anchor Link

# networking (pass explicit values to override published CLI 5.1.0 defaults)
--host "127.0.0.1"
--port 8080
--api-key "your-secure-key"

# session identity
--session-id sales

# runtime helpers
--pm2
--tunnel

# licensing
--license-key "YOUR-LICENSE-KEY"

# isolate explicit chat-triggered code/tool execution
--sandbox-chats
--sandbox-isolation container

Pass linkCode explicitly in an embedded createClient configuration. The shared config loader maps WA_LINK_CODE, but direct createClient calls do not load environment variables automatically. The published Easy API CLI 5.1.0 does not forward link-code settings and has no --link-code flag, so use its QR flow. Select a config file with --config when you need to choose it explicitly. sandboxChats applies only to code or tools explicitly sent through executeInChatSandbox; it does not create a Chromium session per chat or change ordinary message handlers. The boolean form uses the process policy, while the object form controls the isolation boundary and resource access:

export default defineConfig({
  sandboxChats: {
    isolation: 'container', // worker | process | container
    timeoutMs: 30_000,
    idleTimeoutMs: 300_000,
    memoryMb: 256,
    concurrency: 1,
    filesystem: 'none', // none | read-only | workspace
    network: 'none', // none | allowlist
    networkAllowlist: [],
    env: 'none',
    capabilities: ['sendText'],
  },
});

Container mode is the strong boundary for hostile code. Process mode strips ambient globals, environment, and filesystem permission and applies time/memory/output limits, but Node's permission model is defense in depth rather than a complete security boundary. Worker mode is intended for availability isolation around trusted code. Worker and process policies fail closed if they request filesystem, network, or environment access; those host-access policies require container mode.

Full CLI referenceCopy Anchor Link

These are the major flags most users need when starting the Easy API from the command line.

Other useful runtime flags include --host, --headless, --headful, --use-chrome, --use-lightpanda, --qr-timeout, --dashboard-port, --no-dashboard, --no-ezqr, --ephemeral, --sandbox-chats, --sandbox-isolation, --log-console, --log-level, and --verbose.

The standalone @open-wa/cli entrypoint also accepts output-mode flags such as --interactive, --non-interactive, and --output-mode plain. Those affect terminal output before the runtime config is parsed.

CLI-to-schema mappingCopy Anchor Link

Most CLI flags are thin aliases over config schema fields. For example:

npx @open-wa/wa-automate@5.1.0 \
  --session-id sales \
  --host 127.0.0.1 \
  --port 8080 \
  --api-key "$WA_API_KEY" \
  --license-key "$WA_LICENSE_KEY"

is equivalent to these config fields:

export default {
  sessionId: 'sales',
  port: 8080,
  apiKey: process.env.WA_API_KEY,
  licenseKey: process.env.WA_LICENSE_KEY,
};

Explicit CLI flags win over config-file and environment values. The published CLI 5.1.0 also applies its 0.0.0.0 and 8002 startup defaults after config loading, so always pass --host and --port when those values matter.

Not every flag is a schema field. --config selects which file to load, --pm2 controls process management, and --name controls the PM2 process name.

Deprecated flagsCopy Anchor Link

Some v4-era flags remain as compatibility warnings in v5. Replace them with the documented v5 settings below.

When in doubt, prefer the config schema and the flags in this page over older v4 examples.

Plugins field docsCopy Anchor Link

Use plugins to load reusable integrations into the runtime process.

export default {
  plugins: [
    '@open-wa/integration-webhook',
    '@open-wa/integration-chatwoot',
    './plugins/my-local-plugin',
    '/absolute/path/to/plugin.js',
  ],
};

Each item is a plugin reference. It can be an npm package name, a scoped package name, or a file path. The module must export a default plugin or a named plugin export.

Plugins loaded from plugins are imported during createClient() startup. If a plugin does not expose meta.name, it cannot be registered correctly.

PluginConfig docsCopy Anchor Link

Use pluginConfig for plugin-specific settings. The object is keyed by each plugin's meta.name, not necessarily by the package name.

export default {
  plugins: ['@open-wa/integration-webhook', './plugins/moderation'],
  pluginConfig: {
    webhook: {
      url: 'https://your-app.example/webhooks/open-wa',
      headers: {
        'X-Webhook-Secret': process.env.WEBHOOK_SECRET,
      },
    },
    moderation: {
      enabled: true,
      apiKey: process.env.MODERATION_API_KEY,
    },
  },
};

At startup, open-wa looks up pluginConfig[plugin.meta.name]. If the plugin defines a config schema, that value is validated before it is passed to the plugin's init() function.

Example with pluginCopy Anchor Link

import { defineConfig } from '@open-wa/config';

export default defineConfig({
  sessionId: 'support',
  port: 8080,
  host: '0.0.0.0',
  apiKey: process.env.WA_API_KEY,
  webhook: process.env.WA_WEBHOOK,
  plugins: [
    '@open-wa/integration-webhook',
    './plugins/internal-audit-plugin',
  ],
  pluginConfig: {
    webhook: {
      url: process.env.WA_WEBHOOK,
      headers: {
        'X-Webhook-Secret': process.env.WEBHOOK_SECRET,
      },
    },
    'internal-audit': {
      enabled: true,
      logLevel: 'info',
    },
  },
});

Secret managementCopy Anchor Link

Keep secrets out of committed config files. Use environment variables for apiKey, licenseKey, webhook secrets, Chatwoot tokens, and plugin API keys.

For local development, keep the .env file in .gitignore. In production, use the platform secret store or a secret manager. Do not log complete config objects. Nested pluginConfig values frequently contain tokens.

Session events worth knowing aboutCopy Anchor Link

If you need QR images, session-data capture, or low-level launch state, read Session events.

One important caveatCopy Anchor Link

The old Docusaurus site generated a complete CLI options table at build time. This page gives the common flags first. The detailed config surface must agree with the generated reference and runtime schema.
