S3 media storage

@open-wa/integration-s3@5.1.0 listens for message.received, decrypts media that has a deprecatedMms3Url, uploads it through pico-s3, and adds cloudUrl to the message object. It does not remove or replace the original WhatsApp fields. This package exports the s3Plugin(config) factory; it is registered directly with createClient() rather than loaded from the CLI's string-based plugins list.

Configure the pluginCopy Anchor Link

Install the public client, Puppeteer driver, and integration in the Node.js project:

npm install @open-wa/wa-automate@5.1.0 @open-wa/driver-puppeteer@5.1.0 @open-wa/integration-s3@5.1.0

Use a provider value accepted by the integration source. provider, accessKeyId, secretAccessKey, and bucket are required; region is optional.

// app.mjs
import { PuppeteerDriver } from '@open-wa/driver-puppeteer';
import { createClient } from '@open-wa/wa-automate';
import { s3Plugin } from '@open-wa/integration-s3';

const client = await createClient({
  sessionId: 'sales',
  driver: new PuppeteerDriver(),
  plugins: [s3Plugin({
    provider: 'aws',
    bucket: process.env.OPENWA_MEDIA_BUCKET,
    region: process.env.OPENWA_MEDIA_REGION || 'eu-west-2',
    accessKeyId: process.env.OPENWA_MEDIA_ACCESS_KEY_ID,
    secretAccessKey: process.env.OPENWA_MEDIA_SECRET_ACCESS_KEY,
    public: false,
    directory: 'DATE_CHAT',
    ignoreHostAccount: true,
    headers: { 'Cache-Control': 'private, max-age=3600' },
  })],
});

await client.start();

The provider union currently contains aws, gcp, do, wasabi, and backblaze. The integration source has no endpoint option, so do not copy an endpoint-based configuration from a generic S3 SDK. Provider credentials, region rules, bucket policy, and object URL behavior still belong to the provider you select.

What changes on a messageCopy Anchor Link

The plugin runs only when all of these conditions are true:

1. The message has deprecatedMms3Url and mimetype.
2. A decryptMedia client is available to the plugin.
3. ignoreHostAccount does not exclude a message sent by the host account.
4. Decryption and upload succeed.

On success, the plugin keeps the original WhatsApp fields and assigns cloudUrl to the same message object after its asynchronous decrypt and upload finish. It does not emit a separate upload-complete event. Since event listeners run independently of that asynchronous hook, a message.received listener must not assume cloudUrl is already set when it runs.

Await a URL in your own message handlerCopy Anchor Link

Use one upload path for a message. If later work needs the URL immediately, use the integration's exported S3Uploader in your own awaited handler instead of registering s3Plugin for the same messages:

import { Client, createClient } from '@open-wa/wa-automate';
import { PuppeteerDriver } from '@open-wa/driver-puppeteer';
import { S3Uploader } from '@open-wa/integration-s3';

const mediaConfig = {
  provider: 'aws',
  bucket: process.env.OPENWA_MEDIA_BUCKET,
  region: process.env.OPENWA_MEDIA_REGION || 'eu-west-2',
  accessKeyId: process.env.OPENWA_MEDIA_ACCESS_KEY_ID,
  secretAccessKey: process.env.OPENWA_MEDIA_SECRET_ACCESS_KEY,
  public: false,
  directory: 'DATE_CHAT',
  ignoreHostAccount: true,
};

const runtime = await createClient({
  sessionId: 'sales',
  driver: new PuppeteerDriver(),
});
const client = new Client({
  client: runtime,
  transport: runtime.getTransport(),
});
const uploader = new S3Uploader(mediaConfig, {
  error: (message) => console.error('S3 upload failed', message),
});

function getBase64Payload(dataUrl) {
  const match = typeof dataUrl === 'string'
    ? /^data:[^,]+;base64,([A-Za-z0-9+/]+={0,2})$/.exec(dataUrl)
    : null;
  if (!match) throw new Error('decryptMedia did not return a base64 data URL');
  return match[1];
}

client.onMessage(async (message) => {
  if (!message.deprecatedMms3Url || !message.mimetype) return;

  const cloudUrl = await uploader.uploadMedia(message, {
    decryptMedia: async (mediaMessage) => {
      return getBase64Payload(await client.decryptMedia(mediaMessage));
    },
  });

  if (cloudUrl) {
    console.info('media copy ready', { messageId: message.id, cloudUrl });
  }
});

await client.start();

This path awaits uploadMedia() and receives either the generated URL or null; the uploader logs decryption and upload failures. During application shutdown, wait for uploader.waitForQueue() and then call uploader.close().

cloudUrl is the URL generated by pico-s3 for the configured provider, bucket, directory, and object name. The original deprecatedMms3Url may expire or require WhatsApp access, so consumers that need later access should store cloudUrl together with the message ID and the access policy they use.

Directory and throughput optionsCopy Anchor Link

directory accepts one of these built-in strategies:

An arbitrary string is used as a literal directory value. The upload queue has capacity for 64 files, runs at most two uploads concurrently, and is rate-limited to two submissions per second. A busy session can therefore queue work rather than complete the upload inline.

If decryption or upload fails, the plugin logs Upload error and leaves cloudUrl unset for that message. It does not provide a durable retry journal or a separate failure event. If your workflow must track unsuccessful copies, add an application-owned record and recovery path; the integration alone does not guarantee archival.

Access control for cloudUrlCopy Anchor Link

The plugin passes public to pico-s3 when uploading and generating the URL, but that option alone does not establish effective access control. Keep the bucket and object policy private where required, and verify how your selected provider serves the generated URL before exposing it to a CRM or browser. Provider-specific signed URL expiry and scope must be configured with that provider.

public: true asks the upload library for a public object URL. Use it only when the bucket policy, object metadata, and retention policy explicitly allow public access, because anyone who obtains that URL may be able to read the media.

Provider support boundaryCopy Anchor Link

The integration advertises the five provider identifiers above through its type contract. Exact endpoint, ACL, signed URL, egress, and lifecycle behavior is provider-specific and is not established by this integration alone. Confirm a provider with a representative upload, private read, expiry, and deletion exercise before making it part of a production workflow.

Compliance boundaryCopy Anchor Link

Uploading media to object storage gives you a copy and a place to apply storage controls. It does not by itself establish healthcare, financial, GDPR, legal-hold, or other regulatory compliance. Your deployment must define retention, deletion, access review, encryption, audit evidence, regional residency, and incident response for the data and provider you choose.
