Node-RED Integration

Node-RED is a low-code visual automation tool. The open-wa Node-RED contribution lets you build WhatsApp flows visually without writing code.

What Is Node-RED

Node-RED is a flow-based programming tool where you connect nodes together to create automations. The open-wa contribution adds WhatsApp-specific nodes for sending, receiving, and managing sessions.

Installation

Install the Node-RED contribution:

npm install @open-wa/node-red-contrib-wa-automate

Or install through the Node-RED palette manager by searching for @open-wa/node-red-contrib-wa-automate.

Available Nodes

Send Node

Send WhatsApp messages through the flow:

• Text messages
• Images and media
• Location
• Contact cards
• Buttons and lists

Configure the target chatId and message content in the node properties.

Receive Node

Receive WhatsApp messages as flow input:

• Incoming messages trigger the flow
• Message payload includes sender, body, type, and metadata
• Filter by chat type (group vs direct)

Session Node

Manage WhatsApp session lifecycle:

• Start and stop sessions
• Monitor session state
• Handle authentication

Media Node

Handle media operations:

• Download media from messages
• Process images and documents
• Upload media for sending

Example Flows

Echo Bot

1. Add a Receive node to capture incoming messages
2. Connect it to a Send node
3. Configure the Send node to reply to the same chatId with the message body

This creates a simple echo bot that repeats any message it receives.

CRM Integration

1. Receive node captures incoming messages
2. Function node formats the data
3. HTTP Request node sends the data to your CRM API
4. Response node sends a confirmation back to WhatsApp

Conditional Routing

1. Receive node captures messages
2. Switch node routes based on message content or sender
3. Different paths handle different message types
4. Each path sends an appropriate response

Connecting to Easy API

The Node-RED nodes connect to a running Easy API instance:

1. Start the Easy API: npx @open-wa/wa-automate --port 8080
2. Configure the Node-RED nodes with the API URL and key
3. Deploy your flow

Troubleshooting

Connection Issues

• Verify the Easy API is running on the configured port
• Check the API key matches
• Ensure the session is authenticated

Message Not Sending

• Check the chatId format (phone number plus @c.us)
• Verify the session is connected
• Check Node-RED logs for error details

Session Disconnected

• The Session node can detect disconnection
• Configure auto-reconnect in the node settings
• Monitor session state in the Easy API dashboard

Related

• Easy API quick start - Start the API
• Integrations overview - Choose the right integration
• Webhooks for business - Alternative integration pattern
