Webhooks for Business

Webhooks let WhatsApp events flow into your existing services without writing custom runtime code. When something public happens in WhatsApp, open-wa sends an HTTP POST to your endpoint.

Use this guide when you want to send events into a CRM, helpdesk, automation platform, or your own backend.

The source-backed v5 alpha path is the webhook integration plugin loaded from config. The CLI still parses --webhook, but current source warns that CLI webhook registration parity is not restored, so do not rely on that flag for delivery in this alpha.

// wa.config.js
export default {
  plugins: ['@open-wa/integration-webhook'],
  pluginConfig: {
    webhook: {
      url: 'https://your-app.example/webhooks/open-wa',
      events: ['message.received', 'session.state.changed'],
      headers: {
        'X-Webhook-Secret': process.env.OPEN_WA_WEBHOOK_SECRET,
      },
    },
  },
};

Current v5 envelope

The v5 webhook integration sends one JSON envelope for every delivery:

{
  "webhookId": "0f5d6a52-2ff2-43d5-9d0d-9c0c8dd5f9d1",
  "sessionId": "sales",
  "event": "message.received",
  "payload": {
    "ctx": {
      "correlationId": "evt_01",
      "ts": 1700000000000
    },
    "message": {
      "id": "false_1234567890@c.us_ABC123",
      "from": "1234567890@c.us",
      "to": "0987654321@c.us",
      "body": "Hello!",
      "caption": "",
      "type": "chat",
      "timestamp": 1700000000,
      "fromMe": false,
      "isGroupMsg": false,
      "isMedia": false
    }
  },
  "timestamp": 1700000000123
}

Copy these three fields first:

Field to store	Current v5 path	Why it matters
Sender	`payload.message.from`	Route the conversation to the right customer/contact.
Text or caption	`payload.message.body` or `payload.message.caption`	Get the human-readable message content.
Message id	`payload.message.id`	Deduplicate retries and avoid processing the same message twice.

Test receiver with raw-body logging

Start with a receiver that logs the raw request before transforming it. That gives you a ground-truth payload when event shapes change.

import express from 'express';

type WebhookEnvelope = {
  webhookId: string;
  sessionId: string;
  event: string;
  payload: unknown;
  timestamp: number;
};

type MessageFields = {
  id?: string;
  from?: string;
  body?: string;
  caption?: string;
};

function isRecord(value: unknown): value is Record<string, unknown> {
  return typeof value === 'object' && value !== null;
}

function parseEnvelope(value: unknown): WebhookEnvelope | null {
  if (!isRecord(value)) return null;
  if (typeof value.webhookId !== 'string') return null;
  if (typeof value.sessionId !== 'string') return null;
  if (typeof value.event !== 'string') return null;
  if (typeof value.timestamp !== 'number') return null;

  return {
    webhookId: value.webhookId,
    sessionId: value.sessionId,
    event: value.event,
    payload: value.payload,
    timestamp: value.timestamp,
  };
}

function getMessageFields(envelope: WebhookEnvelope): MessageFields {
  if (!isRecord(envelope.payload)) return {};
  const message = envelope.payload.message;
  if (!isRecord(message)) return {};

  return {
    id: typeof message.id === 'string' ? message.id : undefined,
    from: typeof message.from === 'string' ? message.from : undefined,
    body: typeof message.body === 'string' ? message.body : undefined,
    caption: typeof message.caption === 'string' ? message.caption : undefined,
  };
}

const app = express();
const rawBodies = new WeakMap<object, string>();

app.use(express.json({
  limit: '2mb',
  verify: (req, _res, buf) => {
    rawBodies.set(req, buf.toString('utf8'));
  },
}));

app.post('/webhooks/open-wa', (req, res) => {
  console.log('raw webhook body:', rawBodies.get(req) ?? '(empty body)');

  if (req.header('X-Webhook-Secret') !== process.env.OPEN_WA_WEBHOOK_SECRET) {
    return res.status(401).send('Unauthorized');
  }

  const envelope = parseEnvelope(req.body);

  if (!envelope) {
    return res.status(400).send('Invalid open-wa webhook envelope');
  }

  const message = getMessageFields(envelope);

  if (envelope.event === 'message.received') {
    console.log(`[${envelope.sessionId}] message ${message.id ?? 'unknown-id'}`);
    console.log('sender:', message.from ?? 'unknown-sender');
    console.log('text:', message.body || message.caption || '(no text)');
  }

  res.sendStatus(204);
});

app.listen(3000, () => {
  console.log('Webhook receiver listening on http://localhost:3000');
});

Do not remove the raw log until your receiver is stable.

For a one-request local test before connecting WhatsApp, send the current envelope shape to your receiver:

curl -i -X POST http://localhost:3000/webhooks/open-wa \
  -H "Content-Type: application/json" \
  -H "X-Webhook-Secret: $OPEN_WA_WEBHOOK_SECRET" \
  -d '{"webhookId":"local-test","sessionId":"sales","event":"message.received","payload":{"message":{"id":"false_1234567890@c.us_ABC123","from":"1234567890@c.us","body":"Hello!"}},"timestamp":1700000000123}'

Expected local test output, illustrative and abbreviated:

Webhook receiver listening on http://localhost:3000
raw webhook body: {"webhookId":"...","sessionId":"sales","event":"message.received","payload":{...}}
[sales] message false_1234567890@c.us_ABC123
sender: 1234567890@c.us
text: Hello!

The local curl request should return HTTP/1.1 204 No Content. If your receiver returns 401, fix the shared secret header. If it returns any other non-2xx status when open-wa delivers a real event, open-wa treats that as a failure and retries according to the reliability rules below. After the one-request test passes, configure open-wa with your receiver URL and send one real WhatsApp message to confirm the production path.

Platform mappings

Create a Zap with Webhooks by Zapier as the trigger.
Choose Catch Hook.
Copy the Custom Webhook URL.
Configure open-wa with that URL.
In later Zap steps, read fields from payload.message, not data.

Useful mappings:

Zapier field	v5 webhook path
Contact / sender	`payload.message.from`
Message text	`payload.message.body`
Media caption fallback	`payload.message.caption`
Deduplication key	`payload.message.id`

Create a scenario.
Add Webhooks > Custom webhook.
Copy the webhook URL.
Configure open-wa with that URL.
Use the parsed JSON module output paths under payload.message.

For message automations, map payload.message.from, payload.message.body, and payload.message.id first.

Create a workflow.
Add a Webhook node with method POST.
Copy the production webhook URL.
Configure open-wa with that URL.
Add a Set or Code node that reads payload.message.

Example n8n Code node expression:

return [{
  json: {
    sessionId: $json.sessionId,
    event: $json.event,
    sender: $json.payload?.message?.from,
    text: $json.payload?.message?.body || $json.payload?.message?.caption,
    messageId: $json.payload?.message?.id,
  },
}];

Common event names

The webhook plugin receives public runtime event names. Common current v5 names include:

Event	Payload focus
`message.received`	`payload.message` contains the inbound message.
`message.any`	`payload.message` contains inbound or outbound message data.
`message.deleted`	`payload.messageId`, `payload.chatId`, and optional `payload.by`.
`ack.changed`	`payload.ack` contains acknowledgment details.
`session.state.changed`	`payload.details.prev` and `payload.details.next` describe state changes.
`group.participants.changed.global`	`payload.change` contains the group participant change.

Reliability

open-wa treats a 2xx response as successful delivery. Network errors, timeouts, and non-2xx responses are failures.

By default, the webhook integration attempts the first delivery plus 3 retries. The retry delay starts at 1000ms and uses exponential backoff.

Attempt	Delay before attempt
First delivery	none
Retry 1	`1000ms`
Retry 2	`2000ms`
Retry 3	`4000ms`

Webhook delivery is at least once. Store payload.message.id for message deduplication and include sessionId in your dedupe key when you run more than one account.

Next step: keep returning a quick 2xx, store the raw event or dedupe key first, then process slower CRM or automation work asynchronously.

Security

Send a shared secret header with every webhook:

// wa.config.js
export default {
  plugins: ['@open-wa/integration-webhook'],
  pluginConfig: {
    webhook: {
      url: 'https://your-app.example/webhooks/open-wa',
      headers: {
        'X-Webhook-Secret': process.env.OPEN_WA_WEBHOOK_SECRET,
      },
    },
  },
};

Verify that header before processing the body, and keep webhook URLs on HTTPS. Message payloads can include names, phone-number-based chat IDs, message text, and media metadata.

Webhook payloads reference - Detailed payload shape and receiver examples
Integrations overview - Choose the right integration
Security and deployment - Production security
