Data models

These are the core runtime models that show up across the client surface, listeners, webhooks, and generated reference pages.

Chat ID narrative

Every message operation starts with a chat ID. For a direct chat, take the phone number in international format, remove formatting, and add the @c.us suffix.

+44 7700 900000
447700900000
447700900000@c.us

Groups use the @g.us suffix. You do not build a group chat ID from a phone number. WhatsApp assigns it when the group is created, and you read it from an incoming group message, a group listing, or resolved invite metadata.

120363025814912345@g.us

LIDs are internal linked device identifiers. They can appear in sender, participant, or lower-level payload fields when WhatsApp needs an internal identity rather than the plain contact chat ID. Treat them as identifiers to preserve and compare, not as phone numbers to format yourself.

The usual conversion flow for a direct chat is:

phone number with country code
plain digits only
digits plus @c.us
chatId used by send, reply, contact, and webhook payloads

Message direction

Use fromMe to tell whether the current session sent the message. When fromMe is false, the message is incoming. When fromMe is true, the message is outgoing.

The from and to fields still matter. On an incoming one-to-one message, from is the contact chat ID and to is your session. On an outgoing message, from is usually your session and to is the recipient chat ID. For group messages, from or chatId is the group chat ID, while author or senderId can identify the participant who wrote the message.

The self field gives the same direction in string form: in for incoming and out for outgoing. Prefer fromMe when you need a boolean check, and use self when you are logging or storing direction labels.

Message

Messages carry the event data you usually handle in listeners and webhooks. The generated table below is the contract, and the notes here explain the fields that are easiest to mix up in production.

Media fields

Media messages still arrive as messages. The type field tells you the broad message kind, such as image, video, audio, ptt, document, or sticker. The isMedia flag is the quick check before you try to decrypt or store binary content.

Common media fields include:

To access the raw bytes, pass the whole message to decryptMedia after you have checked that the message has media metadata.

import { decryptMedia } from '@open-wa/wa-automate';

client.onMessage(async (message) => {
  if (!message.isMedia && !message.mimetype) return;

  const media = await decryptMedia(message);
  // Save, inspect, or forward the decrypted data from here.
});

Do not assume body contains file bytes. For media, read caption for user text and decrypt the message when you need the content.

Nullability patterns

Most IDs and timestamps are expected to be present because they are needed to route and order events. Optional content fields depend on the message type and on how much data WhatsApp exposed for that event.

Common patterns:

When storing messages, model optional fields as optional or nullable even when your current payload sample includes them. WhatsApp payloads vary by message type, session state, and runtime version.

Sample payloads

A simple incoming text message has a contact chat ID in from, your session in to, and fromMe: false.

{
  "id": "false_447700900000@c.us_3EB0A1B2C3D4E5F67890",
  "body": "Hi, is my order ready?",
  "type": "chat",
  "t": 1768848000,
  "timestamp": 1768848000,
  "from": "447700900000@c.us",
  "to": "15551234567@c.us",
  "chatId": "447700900000@c.us",
  "fromMe": false,
  "self": "in",
  "isGroupMsg": false,
  "isMedia": false,
  "isNotification": false,
  "ack": 1,
  "sender": {
    "id": "447700900000@c.us",
    "pushname": "Aisha",
    "isMyContact": true,
    "isWAContact": true
  }
}

An outgoing group message uses the group chat ID as the conversation target and sets fromMe: true.

{
  "id": "true_120363025814912345@g.us_3EB0F00D112233445566",
  "body": "I will post the notes here.",
  "type": "chat",
  "t": 1768848120,
  "timestamp": 1768848120,
  "from": "15551234567@c.us",
  "to": "120363025814912345@g.us",
  "chatId": "120363025814912345@g.us",
  "fromMe": true,
  "self": "out",
  "isGroupMsg": true,
  "isMedia": false,
  "isNotification": false,
  "ack": 2,
  "author": "15551234567@c.us"
}

A media message may have no useful body. Use caption for attached text and mimetype plus mediaData for decryption.

{
  "id": "false_447700900000@c.us_3EB09988776655443322",
  "body": null,
  "caption": "Receipt from today",
  "type": "image",
  "mimetype": "image/jpeg",
  "t": 1768848240,
  "timestamp": 1768848240,
  "from": "447700900000@c.us",
  "to": "15551234567@c.us",
  "chatId": "447700900000@c.us",
  "fromMe": false,
  "self": "in",
  "isGroupMsg": false,
  "isMedia": true,
  "isMMS": true,
  "isNotification": false,
  "mediaData": {
    "type": "image",
    "mediaStage": "RESOLVED",
    "mimetype": "image/jpeg",
    "filehash": "8f2b5f7b4c0a1d2e3f4a5b6c7d8e9f00"
  }
}

Contact

Contact objects describe a person or WhatsApp identity. The stable field is id, which is the contact chat ID. Display fields are optional because the runtime may know a saved name, a push name, both, or neither.

Common contact fields include name, shortName, pushname, formattedName, isBusiness, isEnterprise, isMe, isMyContact, isUser, isWAContact, labels, profilePicThumbObj, verifiedName, isOnline, and lastSeen.

Treat contact display data as helpful context, not as identity. Use id for lookups, message targets, and deduplication.

Chat

A chat object describes the conversation container. For a one-to-one chat, id points at a contact chat ID and isGroup is false. For a group chat, id uses @g.us, isGroup is true, and groupMetadata may be present.

Common chat fields include id, name, formattedTitle, isGroup, contact, groupMetadata, presence, unreadCount, lastReceivedKey, msgs, isReadOnly, muteExpiration, pin, and ack.

Some chat fields are snapshots. For example, unreadCount, presence, and lastReceivedKey can change between events. Read them as current runtime context, not permanent facts.

Group metadata

Group metadata describes the group itself rather than a single message. The required fields are id, subject, creation, and participants. Admin and configuration fields are optional because they depend on what the session can see and what WhatsApp has exposed for that group.

Common group fields include owner, desc, descTime, descOwner, restrict, announce, and participants. Each participant has an id, an isAdmin flag, and may include isSuperAdmin.

Use the group id as the chat ID for sending messages. Use participant IDs when mentioning, moderating, or showing who sent a group message.
