How it works

Use this page to understand what has to be running before your code can send messages, receive events, or expose WhatsApp through an API. By the end, you should know which process owns the browser session, where readiness comes from, and whether to start with Easy API, custom code, or a remote consumer.

Mental model

Think of the stack like this:

Runtime flow

The same runtime can be reached directly from your app, through the Easy API, or through remote consumers:

Browser session
  WhatsApp Web
    |
    v
Runtime bridge injected by open-wa
    |
    v
Client surface
  actions, listeners, lifecycle, events
    |
    +--> Library mode
    |      your Node.js process calls createClient()
    |
    +--> Easy API
    |      HTTP commands, generated docs, webhooks, MCP
    |
    +--> Remote consumers
           SocketClient, Cloudflare proxy, external services

The browser is still the source of truth. The other layers decide how your code reaches that browser-backed client.

Browser injection

open-wa starts or connects to a browser page, loads WhatsApp Web, then registers the bridge code inside that page. The bridge gives the Node.js side a controlled way to call WhatsApp Web capabilities and listen for runtime events.

Injection is treated as part of session readiness, not just a setup detail. The runtime checks that the bridge, store, and required methods are present before the client is considered ready. If a navigation or reload removes the bridge, the runtime can detect that and run a reinjection path before exposing the session again.

API/Socket/MCP flow

The public surfaces sit on top of the same client surface:

• Easy API receives HTTP requests, checks lifecycle readiness, and calls the matching client method.
• SocketClient connects to a running Easy API instance, sends commands over the remote API path, and listens for runtime events from that process.
• MCP exposes Easy API methods as tools for AI agents. Tool execution is blocked until the session is connected and ready.

That means remote consumers do not own the browser. They talk to the process that owns the browser.

Lifecycle states

A session usually moves through these operational states:

1. starting: the runtime is resolving config, opening the browser, and preparing the page
2. QR: the browser needs authentication and a QR code or link-code flow is available
3. authenticated: WhatsApp Web has accepted the login, but the runtime may still be syncing, injecting, or validating
4. ready: the bridge is usable and client methods can run safely
5. stopping: shutdown has started and listeners, queues, plugins, and browser resources are being drained
6. stopped: the process has released the browser/runtime resources for that session

In code, some of these are emitted through lower-level names such as STARTING, AUTHENTICATING, READY, and STOPPED. The docs use the practical names above because they match what operators see during startup and shutdown.

Session-data storage

Modern session persistence is browser-profile based. Unless you opt into ephemeral, open-wa resolves a userDataDir for the browser profile. If you do not provide one, it derives a directory from the session id, usually ./_IGNORE_<sessionId> relative to the configured sessionDataPath or the current working directory.

That profile contains the browser state needed for WhatsApp Web to restore the login after restart. If you provide userDataDir, the runtime uses your path instead.

Legacy JSON session restore still exists for migration. In that path, open-wa looks for <sessionId>.data.json under sessionDataPath, or treats sessionDataPath as the full file path if it already ends in .data.json. On logout cleanup, that file can be marked LOGGED OUT or deleted, and the userDataDir can also be removed when configured.

The CLI may also create .open-wa/chrome-executable-path.json to cache the resolved Chrome executable path. That file is runtime convenience data, not WhatsApp authentication state.

Where plugins fit

Plugins sit after the core event emitter and before external integrations:

Runtime events
  |
  v
HyperEmitter
  |
  v
PluginHost
  |
  +--> plugin hooks
  +--> plugin routes
  +--> plugin dashboard pages
  +--> plugin tools
  |
  v
External services
  webhooks, Chatwoot, S3, custom integrations

This keeps the browser and client lifecycle inside open-wa, while plugins extend what happens around events, routes, tools, and integration output.

Security-filtered event pipeline

Plugins do not receive the raw internal event bus. PluginHost creates an event gateway for each plugin, and that gateway only allows subscriptions to public, non-sensitive events.

Internal launch, patch, persistence, webhook delivery, server, and license events are blocked from plugin event subscriptions. Sensitive authentication events, such as QR and link-code payloads, are also blocked. Plugins can listen to public message, ack, session, group, chat, device, call, UI, label, story, commerce, reaction, core, and error events.

The gateway also does not expose emit(). Plugins consume events and provide hooks, routes, pages, or tools, but they do not get a direct write handle to the core event bus.

Why sessions matter so much

Most operational questions in open-wa are really session questions:

• how is the session authenticated?
• where is its state stored?
• how is it restored after restart?
• which process owns it?
• how do remote consumers reach it?

Answer those questions before choosing a guide. They decide whether you need a startup/auth flow, a multi-session plan, a remote consumer, or a proxy in front of the Easy API.

The three main usage modes

What to do next

• Start with Easy API mode when you need a running WhatsApp-backed HTTP API quickly.
• Use Library mode when your Node.js app must own browser startup, lifecycle, and event handling directly.
• Use Remote-consumer mode when another service should talk to an Easy API process that already owns the browser session.

Whichever path you choose, confirm the session reaches ready before sending commands, keep session data somewhere durable if you need restarts to survive, and put API keys or proxy tokens in front of any remote surface.
